Helix V EIGHT DSP

Описание

Output power RMS / max.
- @ 4 Ohms    75 / 150 Watts per channel
- @ 2 Ohms    120 / 240 Watts per channel
- @ 1 Ohm    -
- bridged @ 4 Ohms    -
- bridged @ 2 Ohms    -
Amplifier technology    Pure Class GD
Inputs    6 x RCA / Cinch
6 x Highlevel speaker input
1 x Optical SPDIF (12 - 96 kHz)
1 x Remote In
Input sensitivity    RCA / Cinch 2 - 4 Volts or 4 - 8 Volts
Highlevel 5 - 10 Volts or 10 - 20 Volts
Input impedance RCA / Cinch    10 kOhms
Input impedance highlevel    13 Ohms oder 13 kOhms
Outputs    8 x Speaker output
2 x RCA / Cinch
2 x Remote Out
Output voltage RCA / Cinch    3 Volts RMS
Frequency response    20 Hz - 22,000 Hz
DSP resolution    64 Bit
DSP power    295 MHz (1.2 billion MAC operations/second)
Sampling rate    48 kHz
DSP type    Audio signal processor
Signal converters    A/D: BurrBrown
D/A: BurrBrown
Signal-to-noise ratio digital input    105 dB (A-weighted)
Signal-to-noise ration analog input    100 dB (A-weighted)
Distortion (THD)    < 0.015 %
Damping factor    > 70
Operating voltage    10.5 - 16 Volts (max. 5 sec.down to 6 Volts)
Idle current    540 mA
Max. remote output current    500 mA
Fuse    2 x 30 A LP-Mini-fuse (APS)
Additional features    HEC slot, ADEP circuit, Auto Remote switch, Control Input
Dimensions (H x W x D)    44 x 220 x 180 mm /
1.73 x 8.66 x 7.09“
